The four series of reducers occupy a considerable share in modern industrial reducers.The four series of reducers adopt serialization and modular design ideas, have wide adaptability, and have many motor combinations and installation positions.And structurally, the transmission ratio can be finely graded to meet different working conditions and realize mechatronics.Let me introduce the K series reducer in detail in the next four series.
1. K series reducers are manufactured in accordance with international technical requirements and have high technical content.
2. This series of gear reducers is space-saving, reliable and durable, with high overload capacity, and the power can reach more than 200KW.
3. Low energy consumption, superior performance, and the efficiency of the reducer is as high as 95%.
4. K series spiral bevel gear reducer has low vibration, low noise and good energy saving effect.
5. Use high-quality section steel, rigid cast iron box, and the surface of the gear is subjected to high-frequency heat treatment.
6. After precision machining, the reducer that constitutes the helical gear, bevel gear and bevel gear transmission assembly is equipped with various types of motors, forming a mechatronics, which fully guarantees the quality characteristics of gear motor products.
Features:
1. Vertical output, compact structure, tooth surface transmission torque hardening, high-precision gears to ensure stable work, low noise and long life.
2. Installation method: foot installation, hollow shaft installation, flange installation, torque arm installation, small flange installation.
3. Input method: motor direct connection, motor belt connection or input shaft, connection flange input.
4. Output mode: hollow shaft output or solid shaft output, the average efficiency is 94%.
5. Combined use with R series can get bigger speed ratio.
Technical Parameters:
Speed ratio range: basic type 5.36~197.37, K series/R series combined type can reach 32625
Torque range: 200~50000 Nm
Power range: 0.18~200kW
structure type:
K axis extension, foot mount KA axis mount connection
KF Shaft Extension, Flange Mount KAF Shaft Mount, Flange Mount
