How to calculate the slip rate of worm gear reducer: calculation examples of lead angle, sliding speed and meshing efficiency - Hangzhou Weigao Transmission 2026-11-10
Let’s clarify the total parameters of the sliding rate ν of the worm gear reducer: the linear speeds of the worm and the worm gear indexing circle are perpendicular to each other, the relative sliding speed of the contact point v_s=v1/cosγ=v2/sinγ, the sliding rate ν=v_s/v2=1/sinγ, which is only determined by the module, the diameter of the worm indexing circle and the number of heads. Using a 5.5 kW, 20:1 reducer example (m=4, d1=40, z1=2, z2=40), the calculation results are γ=11.31°, ν=5.10, v_s=3.097 m/s, and the equivalent friction angle table shows that the meshing efficiency is 0.87, the total efficiency is 0.82, and the heating power is 0.98 kW, and the calculation method of the worm gear material according to the sliding speed and the thermal balance heat dissipation area of 1.12~1.75 m² is given.
