  • Selection and precautions of servo planetary reducer model

    2023-05-25

    When choosing a servo planetary reducer model, you must first understand the reduction ratio and torque calculation, because these two parameters are very important.The model selection of the servo planetary reducer is as close as possible to the ideal reduction ratio: Ideal reduction ratio = servo motor speed ÷ reducer output shaft speed torque calculation is very important for the service life of the servo planetary reducer, and the maximum torque value of the acceleration should be paid attention to (TP), whether the maximum load torque of the reducer is exceeded.Torque calculation formula: T=9550P/n In addition, the applicable power is generally the power applicable to the servo planetary reducer on the market. The applicability of the reducer is extremely high, and the work coefficient can be maintained above 1.2. Decide according to your own needs.Selection points of the servo planetary reducer model 1. The output shaft diameter of the selected servo motor should not be greater than the maximum shaft diameter used in the table.2. If the torque calculation works, the speed can meet the normal operation, Read More
  • What factors are related to the size of the servo planetary reducer?

    2023-05-25

    Whether it's design input from a potential customer or the specification of a new standard product line, the performance requirements of your application are critical to sizing your servo planetary gearbox.The size of a servo planetary gearhead is primarily determined by performance requirements: Speed ​​- How fast does the application require the output shaft to turn?Torque - What is the torque load requirement?Overhung Loads - External radial loads applied to the output shaft may require greater gear load capacity and therefore larger gears.Shutdown - How long does the servo planetary reducer run before shutting down?Depending on service life requirements, smaller gearboxes can be used for intermittent duty applications.Lifetime - How many cycles or continuous hours are required to meet the desired lifespan?Compared to Design 4000 Hours, Design 400 Hours has a large difference in size.Often the most critical factor in any product, cost caps influence many design choices.Servo planetary gear reducer materials and processing options account for a large part of the total cost Read More
  • Application tips of servo planetary reducer

    2023-05-18

    Before, I shared a lot about the problems and solutions that will occur during the use of the servo planetary reducer. In this article, I still share with you the application tips of the servo planetary reducer.Bappman Industrial Technology interprets the application tips of the servo planetary reducer from three aspects: environment, lubricating oil addition, maintenance, etc., as follows: The environment of the application tips of the servo planetary reducer: The reducer is a precision instrument , although its appearance and working environment make it more durable, it cannot be denied its precision and fragility.It requires us to ensure that the environment and changes of the reducer are consistent with the working requirements of the reducer when we use the reducer.Application Tips for Servo Planetary Reducer Lubricating Oil Addition: Adding lubricating oil: The grade of lubricating oil should be the recommended value of the reducer, or use lubricating oil that is completely equivalent to the recommended oil.The amount of oil should be accurate, each reducer has a mark indicating the recommended grade of oil Read More
  • How to improve the use quality of planetary reducer?

    2023-05-18

    The use of mechanical equipment is the most common situation, and as the most important transmission equipment in modern industry, the long service life of planetary reducer will make users very satisfied, because you can save a lot of money to buy replacement machinery.And it is not easy to know that it is not easy to replace the planetary reducer, which not only affects the normal production rhythm, but also consumes a lot of manpower and cost for the update.Therefore, in order to prolong the service life of the planetary reducer, work hard on the maintenance of the machine, and the maintainability is good, which not only prolongs the mechanical life, but also greatly improves the quality of use of the planetary reducer.In order to prolong the service life of the machine and improve the quality of operation, the following two points should be paid attention to: One is to enrich the theoretical knowledge about the principle of the planetary reducer.Because of the full understanding of the working principle of the planetary reducer, it is very helpful to understand the application of the planetary reducer in the work.This avoids some low-level errors.The second is to constantly discover new materials Read More
  • Inspection and precautions for oil quality of planetary reducer

    2023-05-18

    Since the special oil for the planetary reducer may deteriorate after the equipment has been in operation for a long time, which will seriously affect the use of the equipment, and more seriously, it may cause damage to the equipment and reduce the use efficiency. Therefore, we should treat the oil according to the requirements of the planetary reducer The oil quality of the equipment is checked regularly to ensure the normal use of the equipment.In fact, the use effect of the planetary reducer has a lot to do with its oil quality. You must not ignore the inspection of the oil quality during use.So, how should the oil of the planetary reducer be checked?The specific method of Bappman Industrial Technology is described in detail below: 1. The lubricating grease of the reducer will be mildewed due to various reasons within a period of time after use, so it is necessary to check the lubricating grease every quarter; 2. Check the oil , first turn off the switch power supply, wait for the reducer to turn on after water cooling, place a non-porous oil receiving plate under the oil filling foot of the reducer, then open the oil level oil foot bolt, add some oil Read More
  • How to reduce the safety hazard of planetary reducer?

    2023-05-10

    Probably everyone knows that no product can be 100% good, and the planetary reducer is the same. Since it cannot be perfect, it is necessary to prevent hidden dangers. The installation of the planetary reducer requires professional operation, and the accessories and materials used Guaranteed ones should also be used, so that the potential safety hazards can be reduced during production.Potential safety hazards of planetary reducers: Installed in places with poor environmental conditions, when the inhaled air contains particles, dust, corrosive gases, etc., it will not only affect the service life of the compressor lubricating oil, but may also cause fire related to inhaled particles and explosion accidents.Bappman Industrial Technology recommends that you consider installing an air intake filter, which should be cleaned frequently and replaced regularly.Before using the planetary reducer, the user should first understand the use method and precautions of the planetary reducer. It not only involves the use of the machine itself, but also needs to ensure the safety of the current when using electricity. Read More
